MEAN WELL MDR-40-12 AC to DC DIN-Rail Power Supply 12V 3.33 Amp 40W
- Primary output voltage (vdc): 12
- Output current (a): 3.33
- Maximum output power (w): 40
- Family: mdr-40
- Input voltage (vac): 85 to 264
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
40W DIN-RAIL SWITCHING POWER SUPPLY 12 Volts 3.33 Amps Specifications : ? Universal AC input range ? Protections: Short-circuit, Overload, Overvoltage ? 100% Full load burn-in test ? Soft-start circuit, limiting AC surge current ? Input Voltage: 85-264VAC 47-63Hz, or 120-370VDC ? Input Current Full load: 1.1A(115V) / 0.7A(230V) ? Size: 3.9 x 1.6" x 3.5" ? Weight: 0.6 lbs. ? 3-year warranty For more 12 Volt power supplies . Detailed Specifications: ? Primary Output Voltage (VDC): 12 ? Output Current (A): 3.33 ? Maximum Output Power (W): 40 ? Family: MDR-40 ? Input Voltage (VAC): 85 to 264 ? Input Frequency: 47 to 63 ? Maximum Input Current (A): 1.1 ? Output Connector Type: Screw Terminal ? Efficiency (%): 86 ? Operating Temperature-Min (Cell): -20 ? Operating Temperature-Max (Cell): 70 ? Length (inch): 1.57 ? Width (inch): 3.54 ? Height (inch): 3.94 ? Agency Approvals: UL/CUL/TUV/CB/CE ? Color: White ? Style: DIN".
