Specification:
Model Number: TF500W
Max.
Power: 600W
Application: Industrial PC/Checking Machine/All-in-One Machine etc.
Fan Type: 4cm
Name: Flex Power Supply
Input Voltage: 110-230Vac
High Efficiency: 85%
Dimension: 150* 81.5 *40mm
Feature:
In accordance with Flex12V version 2.0
High efficiency
Low output ripple noise
Each output with over voltage protection
Each output voltage with short-circuit protection
4CM fan
100% high temperature aging test (50)
Life cycle: more than 80KH hours
Connector:
6pin to 6+2pin *1
4pin to sata to sata to IDE *1
4pin to 4+4pin *1
14pin to 20+4pin *1
