ASUS XONAR SE Asus XONAR SE 5.1 Channel 192kHz/24-bit Hi-Res 116dB SNR PCIe Gaming Sound Card with Windows 10 compatibility

ASUS XONAR SE Asus XONAR SE 5.1 Channel 192kHz/24-bit Hi-Res 116dB SNR PCIe Gaming Sound Card with Windows 10 compatibility
Specifications
Mfr Part Number: XONAR SE
Features: 5.1 channel, 192kHz/24-bit Hi-Res audio with a 300ohm headphone amp for detailed, immersive sound with punchy, defined bass
Realtek ALC1220X codec delivers a crystal clear 116dB signal-to-noise ratio (SNR)
ASUS Hyper Grounding Technology ensures minimal audio distortion and interference
Xonar Audio Center enables full audio control via an intuitive, spacious interface
Included Low Profile Bracket allows the Xonar to fit perfectly into most systems
Audio Interface: PCI Express
Chipset: Audio Processor - C-Media USB 2.0 6620A High-Definition Sound Processor (Max. 192KHz/24bit)
Audio Performance: Output
Signal-to-Noise Ratio (A-Weighted) (Front-out): 116 dBInput
Signal-to-Noise Ratio (A-Weighted): 110 dBOutput THD+N at 1kHz (Front-out): 0.00251 %(-92 dB)Input THD+N at 1kHz: 0.00251 %(-92 dB)Frequency Response (-3dB, 24bit/192KHz
input): 10 Hz to 87 KHz
Output/Input Full-Scale Voltage: Headphone output - 2 Vrms ( 5.65
Vp-p)Digital-to-Analog Converter (DAC): Realtek S1220A (120dB SNR, Max. 192KHz/24bit)Sample Rate and
Resolution: Analog Playback Sample Rate and
Resolution: 44.1K /48K/96K/192KHz @ 16bit/24bit
Analog Recording Sample Rate and Resolution: 44.1K /48K/96K/192KHz @ 16bit/24bit
S/PDIF Digital Output: 44.1K /48K/96K/192KHz @ 16bit/24bit
ASIO 2.0 Driver Support: 44.1K /48K/96K/192KHz @ 16bit/24bit
Connectivity: Analog
Output: 3x 3.5 mm jack (1/8") (Front out/Side out/Rear out)Analog
Input: 1x 3.5 mm jack (1/8") (Line-in/ Mic-in)
Digital: 1x S/PDIF out (1x Optical (Toslink) )Special
Features: ââ? ¬â? ¹Smart Volume Normalizer
Xear 3DVirtual Speaker Shifter
Xear Surround
Magic Voice
Operating System: Windows 7/ 8.1 / 10
Package Contents: 1x Low-profile bracket, 1x Driver CD, 1x Quick start guide
MPN: XONAR SE
192876040560
