DSD TECH SH-G01A USB Isolator with ADUM3160 Chip 12M
- USB isolator:This USB isolator protect the communication interface between the host, such as a PC, and its peripheral.Through this isolator, the interference of signal noise can be reduced, and at the same time, your computer or laptop can be prevented from being damaged when an accident occurs.
- Maximum support 12Mbps:Support USB full speed 12 Mbps or low speed 1.5 Mbps . Please note: this USB isolator does not support 480 Mbps,So please don't use it to isolate audio noise.
- Industrial grade: Built-in ADI ADUM3160 chip, support iCoupler technology. Signal isolation: 2500V; Voltage isolation: 1500V; Output current: 200mA; Especially suitable for industrial environments.
- Compatibility: This USB isolation adapter is compatible with Windows 7, 8, 10 and various Linux OS and Mac OS
- Warranty:DSD TECH provide a 1 year warranty and lifetime technical support for this USB isolator.if you have any questions, please feel free to contact us. We will respond within 24 hours.
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
The SH-G01A USB isolator protect the communication interface between the host, such as a PC, and its peripheral. Through this isolator, the interference of signal noise can be reduced, and at the same time, your computer or laptop can be prevented from being damaged when an accident occurs. It is very suitable for industrial occasions.
Precautions:
1, Only supports low speed ( 1.5M bps), full speed (12Mbps), and does not support high speed (480Mbps)
2,
The following device types are not compatible: USB wireless network cards, some USB 3.0 flash drives, audio codecs, virtual oscilloscopes, DAC audio decoders and other high-speed USB 3.0 devices.
Specification:
Model: SH-G01A
Main chip: ADI ADUM3160
Supports 1.1, 2.0
Supports Low ( 1.5M bps), Full (12Mbps)
Provides 200mA to the connected USB device
No driver required, no settings to configure
Self powered, no external power needed
Signal isolation: 2500V
Voltage isolation: 1500V
Applications:
Industrial automation systems, Medical devices, Measurement devices, test gear, Environments requiring safety insulation, Machine protection, Broadcast and Studio
WARRANTY:
DSD TECH offers a 12-month warranty on this USB isolator. If you have any questions, please contact us and we will resolve your issue within 24 hours.
Precautions:
1, Only supports low speed ( 1.5M bps), full speed (12Mbps), and does not support high speed (480Mbps)
2,
The following device types are not compatible: USB wireless network cards, some USB 3.0 flash drives, audio codecs, virtual oscilloscopes, DAC audio decoders and other high-speed USB 3.0 devices.
Specification:
Model: SH-G01A
Main chip: ADI ADUM3160
Supports 1.1, 2.0
Supports Low ( 1.5M bps), Full (12Mbps)
Provides 200mA to the connected USB device
No driver required, no settings to configure
Self powered, no external power needed
Signal isolation: 2500V
Voltage isolation: 1500V
Applications:
Industrial automation systems, Medical devices, Measurement devices, test gear, Environments requiring safety insulation, Machine protection, Broadcast and Studio
WARRANTY:
DSD TECH offers a 12-month warranty on this USB isolator. If you have any questions, please contact us and we will resolve your issue within 24 hours.
