1pc R60ABD1 60G Millimeter Wave Radar Module, Respiratory and Sleep Monitoring, 61-61.5GHz, 35x30x5mm; with JU01 Serial Port Adapter Board
- 60GHz MILLIMETER WAVE TECHNOLOGY: Advanced radar sensor operating at 61-61.5GHz frequency detects subtle skin movements to monitor respiratory rate, heart rate, motion amplitude, and abnormal activities for comprehensive health tracking.; CONTACTLESS SLEEP MONITORING: Continuously monitors breathing and sleep patterns within 6.56 feet range, generating detailed sleep quality analysis reports without requiring wearable devices or physical contact with the user.; BUILT-IN ALGORITHM PROCESSOR: Integrated processing unit calculates and outputs results directly through serial port communication without cloud computing, ensuring fast response times and enhanced data privacy for real-time monitoring.; INTELLIGENT PRESENCE DETECTION: Distinguishes between someone present or nobody, active or still states, and detects breathing patterns within 6.56 feet with optimal installation height of 9 feet for accurate human presence sensing.; VERSATILE INSTALLATION: Compact 1.38 inch diameter by 1.18 inch size unit can be mounted on top, slope, or level surfaces with 40-degree horizontal and vertical detection angles, penetrating low-density materials like thin wooden boards.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
60GHz
MILLIMETER WAVE TECHNOLOGY: Advanced radar sensor operating at 61- 61.5GH z frequency detects subtle skin movements to monitor respiratory rate, heart rate, motion amplitude, and abnormal activities for comprehensive health tracking.;
CONTACTLESS SLEEP MONITORING: Continuously monitors breathing and sleep patterns within 6.56 feet range, generating detailed sleep quality analysis reports without requiring wearable devices or physical contact with the user.;
BUILT-IN ALGORITHM PROCESSOR: Integrated processing unit calculates and outputs results directly through serial port communication without cloud computing, ensuring fast response times and enhanced data privacy for real-time monitoring.;
INTELLIGENT PRESENCE DETECTION: Distinguishes between someone present or nobody, active or still states, and detects breathing patterns within 6.56 feet with optimal installation height of 9 feet for accurate human presence sensing.;
VERSATILE INSTALLATION: Compact 1.38 inch diameter by 1.18 inch size unit can be mounted on top, slope, or level surfaces with 40-degree horizontal and vertical detection angles, penetrating low-density materials like thin wooden boards.
MILLIMETER WAVE TECHNOLOGY: Advanced radar sensor operating at 61- 61.5GH z frequency detects subtle skin movements to monitor respiratory rate, heart rate, motion amplitude, and abnormal activities for comprehensive health tracking.;
CONTACTLESS SLEEP MONITORING: Continuously monitors breathing and sleep patterns within 6.56 feet range, generating detailed sleep quality analysis reports without requiring wearable devices or physical contact with the user.;
BUILT-IN ALGORITHM PROCESSOR: Integrated processing unit calculates and outputs results directly through serial port communication without cloud computing, ensuring fast response times and enhanced data privacy for real-time monitoring.;
INTELLIGENT PRESENCE DETECTION: Distinguishes between someone present or nobody, active or still states, and detects breathing patterns within 6.56 feet with optimal installation height of 9 feet for accurate human presence sensing.;
VERSATILE INSTALLATION: Compact 1.38 inch diameter by 1.18 inch size unit can be mounted on top, slope, or level surfaces with 40-degree horizontal and vertical detection angles, penetrating low-density materials like thin wooden boards.
